NTS-PU (direct pull) Series Safety Breakaway Coupling
Protects your equipment, piping and personnel in the event of an unintended pull-away. A consideration whenever you are making a tight connection to a truck or railcar.
SAFER. Protects loading rack facilities, hoses and personnel by preventing damage and spills during a pull-away incident.
CLEANER. High value fluid and gas transfer is protected by two spring energized valves for maximum protection with a minimum of fluid loss.
FASTER. Immediate separation occurs at individually determined straight or angular pulling force. This non-destructive separation allows easy reassembly, with no shear pins, tools or spare parts.
Specifications
| Connections |
FNPT or Flange (150/300#) |
| Sizes |
1", 2", 3", 4", 6" (Sizes up to 12" Available Upon Request) |
| Max. Pressure |
360 PSI (Alu 232 PSI) |
| Materials |
316 Stainless Steel (Anodized Aluminum in 4" size only) |
| Seals |
Fluorocarbon, EPDM, Chemraz® |
| *Other materials available upon request. |
